Computer Control Geotextile Material Testing Machine , Tensile Compression Tester

Name: Computer Control Geotextile Material Testing Machine Tensile Compression Tester
Brand: Marxtest
Price: 1 USD

Place of Origin : Shandong, China (Mainland)

Brand Name : Marxtest

Model Number : WDW-T50

Supply Ability : 50 Set/Sets per Month

Packaging Details : Plywood package for export

MOQ : 1 Set/Sets

Price : US $2,500-6,500 / Sets

Power : Hydraulic

Product name : 50KN Computer control geotextile material tensile testing machine

Model : WDW-T50

Capacity : 50 KN

Measuring range : 1%-100% FS

Accuracy : class 1 (0.5 optional)

Display : Computer

Power supply : 380V 50HZ, can be customized

Material : Geotextile materials

Standard : ASTM E8/A370/ISO 75001

Certificate : ISO CE SGS

Port : Qingdao or other

Contact Now

Computer Control Geotextile Material Testing Machine , Tensile Compression Tester

Overview
The digital geotextile material tensile testing machine is used for various geotextile materials for tensile tests.
Application standards
ASTM E8 - 16 Standard Test Methods for Tension Testing of Metallic Materials
ISO 6892-1 Materials --tensile testing
ASTM D638

Remote control with display

Ergonomically-designed and easy to operate
Test star and stop operation
Crosshead moving up, down, jog up, jog down
Display of measurement channel: force, displacement, extension and etc.
Test status display
Specimen protection function

Technical parameters

Model	WDW-T10KN	WDW-T20KN	WDW-T30KN	WDW-T50KN	WDW-T100KN
Capacity/load	10KN	20KN	30KN	50KN	100KN
Load accuracy	Class 1(Class 0.5 optional)
Load range	1%-100% FS(0.4%-100% optional)
Testing speed	0.001-1000mm/min
Cross head travel	1000mm	1000mm	1000mm	1000mm	1000mm
Effective tensile range	700mm	700mm	700mm	700mm	700mm
Effective test width	400mm	400mm	450mm	450mm	500mm
Load resolution	1/30000
Deformation measuring range	1%-100% FS
Deformation	≤±0.5%
Power supply	AC 220V 50Hz( Can be customized as customers' requirements)

Clamping Fixture Configuration
Tensile grips	Manual wedge fixture or hydrualic automatic clamping fixture
Round specimen clamping range	Φ4-9,9-14,14-20mm
Flat specimen clamping range	0-7,7-14,14-20mm
Compression Plate	Φ170 x 170 mm (can be customized as customer request)
Bending fixture	3-point bending fixture (4-point bending fixture is optional)
Electronic extensometer	YUU10/50

Packing & Delivery

Inner water-proof plastic film packaging

Outer plywood box for export

Shipping time: 10-20 days after payment

FAQ

1. Are your company a trading one or a factory?
Factory + trading company (integration), 21 years focusing on test instruments field, 5 years exporting experience.
2. After an order is placed, when to delivery?
Generally about 15 working days, If we have inventory, we can arrange shipment within 3 working days.
Please be aware that our production lead times depend on specific items and item quantities.
3. What about the warranty with after - sales services?
12 months warranty after delivery. Besides,we can help you to repair your problem controller freely,even it's not from our factory. What you need to do is to send us the controller.
After the warranty, the professional after-sale service team will provide perfect technical support,and help customer solve problems encountered while using our product, handles guest problems and complaints in
a professional and timely.
4. What about the services and product' quality?
Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.
Product use training, each of our product provide video training to show you how to install & operate.
All the products meet with: ISO, ASTM, AATCC, BS, EN, DIN, JIS and other required standards.
